| Gen. 2+ IIT |
| Superior optics |
| Easy to use |
| Long battery life |
The NV 66-G2 night vision goggle provides the ability to observe the terrain under the darkest conditions. This model uses the same approach to night vision as our popular battle-tested NVS 7 series and uses a Generation 2+ image intensifier tube. No export permit is required for this device.
| Gen. 2+ IIT |
| Superior optics |
| Easy to use |
| Long battery life |
| IIT | |
|
Generation |
2+ |
|
Photocathode material |
S-25 |
|
IIT resolution, minimum (lp/mm) |
56 |
|
Signal to noise ratio, minimum |
18 |
| Optics | |
|
Magnification (x) |
1 |
|
Field of view (°) |
40 |
|
Objective F# |
1.2 |
|
Objective focal length (mm) |
27.5 |
|
Focus range (m) |
0.25 – ∞ |
|
Eye relief (mm) |
25 |
|
Diopter adjustment range |
-6 to +5 |
| Mechanics, Electronics & Environmental | |
|
Dimensions (mm) |
130x125x55 |
|
Weight without batteries (g) |
400 |
| Interpupillary distance (mm) | 58-72 |
|
Built-in IR illuminator |
Yes |
|
Reverse polarity protection |
Yes |
|
IR operation indicator |
No |
|
Low battery indicator |
Yes |
|
Automatic brightness control |
Yes |
|
Automatic shut-off system |
Yes |
|
Battery type |
2x AA |
|
Battery life (hours) |
80 |
|
Operating temperature range (°C) |
-50 to +55 |
|
Storage temperature range (°C) |
-55 to +60 |
|
Waterproofing |
IP67 |
